| Indictor |
LCD 12.59 in x 9.44 in (32 cm x 24 cm), with back light |
| Cable Test Types |
STP/UTP 5E, 6E network, telephone, coaxial cable |
| Function 1 |
Continuity, length test |
| Function 2 |
PING, PoE detect |
| Tracing Cable types |
Cat5e, cat6, cat7, telephone cable, coax cable, power cable |
| Length Measurement |
3.3 feet to 6561.7 feet (1 m to 2000 m) |
| Max. Distance of Wire map |
3.280 ft (1000 m) |
| Max. Distance of Tracing |
3.280 ft (1000 m) |
| Max. Distance of Cable Length |
3.280 ft (1000 m) |
| Max. Distance of Calibration |
164 ft (50 m) |
| Accuracy |
up to 98% (after calibration) |
| Compatible Connectors |
RJ11, RJ45, PING/POE, BNC |
| Cable Map Indication |
LCD (#1-#8) |
| Cable Hunting |
RJ11, RJ45, BNC |
| Battery Type |
3.7 V lithium battery 1800 mAh |
| Types of Cable |
≥ 2 cores |
| Battery Type |
3.7 V lithium battery 1800 mAh |
| Dimension |
7.2 in x 3.3 in x 1.4 in (18.3 cm x 5.8 cm x 3.5 cm) |
| Transmitter Size |
7.3 in x 3.15 in x 1.3 in (18.5 cm x 8 cm x 3.2 cm) |
| Dimensions |
4.17 in x 1.25 in x 1.18 in (10.6 cm x 3.2 cm x 3 cm) |
| Work Temperature / Humidity |
50 ℉ to -76 ℉ (10 ℃ to -60 ℃) / 32 ℉ to 158 ℉ (0 ℃ to 70 ℃) |
