Description
Features
- Waterproof Ring
- Nut
- Blade
- N Female Type
Technical Specifications
| Category | Details |
| Type | Cellular Antenna |
| Frequency Range | 824 to 2690 MHz |
| Gain | 3 dBi |
| VSWR | ≤ 2 |
| Input Impedance | 50 Ω |
| Polarization | Vertical |
| Radiation Direction | Omnidirectional |
| Maximum Power | 20 W |
| Connector Type | N-K Male |
| Installation | Screw port docking |
| Antenna Height | 7.12 in ± 0.04 in (181 mm ± 1 mm) |
