Description
Overview
Asset Track Pro industrial Panel personal computer, equipped with LED LCD screen, with anti-light interference, sunlight, incandescent lamp, fluorescent lamp and other strong light changes when normal use, 10 point standard projection capacitive touch screen, high sensitivity, fast response, can achieve multi-touch functions such as zoom in and zoom out pictures, default configuration: industrial motherboard J4125+4G memory +128G solid storage.
Technical Specifications
| SOC | J4125 (Optional: J6412, industrial control board i3, i5) |
| OS | Win7 or Win10 or Linux |
| Storage | 1 x M.2 2280 Interface support NVME and SATA Dual protocol (adaptive) |
| Graphics Card | Core graphics card (independent graphics card can be customized) |
| Network | Integrated 10,100,1000M adaptive network card, wireless network card 802.11a,b,g,n |
| I O PORT | Front out 2 x RS232 Rear out 2 x HDMI,4 x USB, 2 x LAN, 1 x MIC IN, 1 x LINE OUT |
| Power Input | 12V 5A |
| Humidity | 0% to 90% |
| Operating Temperature | 14°F to 140°F (-10°C to 60°C) |
| Storage Temperature | 32°F to 140°F (0°C to 60°C) |
| Size | Bare computer 10.13 in x 6.94 in x 1.79 in (257.4 x 176.4 x 45.5mm) Mounting foot 13.78 in x 9.25 in x 4.72 in (350 x 235 x 120mm) |
