Description
Features
- Built on VFL
- Support Phone Charging
- Waveform Display
- Dust Proof Protection
Technical Specifications
| Wavelength | 1310/1550 nm |
| Wavelength | KP-500-A: 1550 nm, KP-500-B: 1310/155 0nm |
| Fiber Type | SM (Single Mode) |
| OTDR Connector | FC/PC or customized |
| Event Dead Zone | 6.56 ft (2 m) |
| Attenuation Dead Zone | 26.24 ft (8 m) |
| Distance Setting | Max 49.71 mi (80 km) |
| Testing Range | -50 dBm to +26 dBm |
| Calibration Wavelength | 850/1300/1310/1490/1550/1625 nm |
| Response Wavelength | 700 nm to 1700 nm |
| VFL | Support |
| Pulse Width | 5 ns to 10 µs |
| Measuring Time | 5 s to 180 s |
| Operate Temperature | 32 ℉ to 122 ℉ (0 to 50 degree C) |
| Data Storage | 500 |
| Battery | 3.7 V, 2400 mAh |
| Operating Environment | 14 ℉ to 122 ℉ (-10 °C to + 50 °C) |
| Size | 6.61 in x 3.74 in x 1.49 in (16.8 cm x 9.5 cm x 3.8 cm)(LWH) |
