Description
Features
- Detailed test reports
- Dust-proof silicon buttons
- Event points analysis
- VR and OPM support
Technical Specifications
| Storage | Internal memory or TF card (optional) |
| Fiber Type | SM (Single Mode) |
| Distance Setting | Max Boam |
| OTDR Connector | FC/PC or customized |
| Event Dead Zone | 6.56 ft (2 m) |
| Attenuation Dead Zone | 26.24 ft (8 m) |
| Pulse Width | 505 to 105 |
| Measuring Time | 5 to 1805 |
| Sampling Points | 8000 |
| Linearity | ±0.03 dB/dB |
| Index of Refraction | 1.0000 to 2.0000 |
| Testing Range | -50 to -26 dBm |
| Calibration Wavelength | 850/1300/1310/1490/1550/1525nm |
| Rating Range | KP-9000-5008 |
| LCD | 3.2-in LCD |
| Communication Interface | Micro USB × 1 |
| Battery | 3.7 V, 2400mAh Lithium battery |
| Battery Endurance | Standby > 8h, Test > 4h |
| Operating Temperature | 32 ℉ to 122 ℉ (0 °C to 50 °C), <90% RH |
| Storage Temperature | -4 ℉ to 158 ℉ (-20 °C to +70 °C), 90% RH |
| Dimension | 0.55 in x 0.31 in x 0.12 in (16.8 cm × 9.5 cm × 3.8 cm) |
| Weight | < 12.34 oz (350 g) |
