Description
Features
- Portable, Rugged, Lightweight Design
- Accurate Testing, Better Repeatability
- Automatic Pulse Width Control
- Built-in Visual Fault Locator
Technical Specifications
| Wavelength | 1310 nm or 1550 nm |
| Type of fiber | 9/125um SM Fiber |
| Connecter | FC/SC/PC |
| Dynamic Range | 22 dB |
| Pulse Width | 5 ns to 8000 ns, Auto |
| Measurement | M |
| Event blind zone | 9.84 ft (3 m) |
| Attenuation blind | 32.80 ft (10 m) |
| Range accuracy | 3.28 ft (1 m) +2 x 10-4 x distance) |
| OPM | -50 dBm to +26 dBm |
| 850/1300/1310/1490/1550/1625 nm | |
| VFL | ≥10 mW |
| Optical Light Source | 1550 nm |
| Powe supply | 3psc of Dry battery |
| Battery Work time | ≥2000 times measure |
| Save Data | >500 |
| Work Temperature | 23 ℉ to 104 ℉ (-5 ℃ to 40 ℃) |
| SAve Temperature | 14 ℉ to 140 ℉ (-10 ℃ to 60 ℃) |
| Humidity | 0% to 85% (no condensation) |
| Net Weight | 10.58 oz (300 g) |
