Description
Features
- 26dB Dynamic Range
- 80km Precision Test
- Dual-Wavelength OTDR
- Super-Long Standby (20h)
Technical Specifications
| Reflection Accuracy | Class II |
| Data Storage | SOR Standard file format |
| Laser Safety Level | Class II |
| File Format | SOR Standard file format |
| Connector | FOUPC (Interchangeable SC, ST) |
| Interface Type | Universal Joint POSOST |
| Ranging Accuracy | 3.28 ft (1 m) Sampling interval +0.005% Test distance |
| Wavelength | 1310 nm/1550 nm ± (2 cm) |
| Fiber Type | G.652 |
| Dynamic Range | 26 dB/24 dB |
| Event Blind Zone | 8.20 ft (2.5 m) |
| ATT Blind Zone | Sm |
| Test Range | 1.64 ft to 79.53 mi (500 m to 128 km) |
| Pulse Width | J ns to 10 us |
| Loss Accuracy | 164 to 128k |
| Sampling Points | 0.164 ft to 16.40 ft (0.05 m to 5 m) |
| Sampling Resolution | Internal: 2600, External: TF Card |
| OPM Wave Range | 31.49 in to 66.92 in (80 cm to 170 cm) |
| Test Range (OPM) | 50 dBm to 26 dBm |
