| Testing Wavelength |
1310 to 1550nm, 850 to 1300nm, 1310 to 1490 to 1550nm, 1310 to 1490 to 1625nm, 850 to 1300 to 1310 to 1550nm |
| Dynamic Range |
32 to 30dB, 35 to 33dB, 38 to 36dB, 26 to 28dB, 38 to 35 to 36dB, 28 to 30 to 42 to 38dB |
| Pulse Width |
3ns to 500ns |
| Testing Distance |
(500 m) 1,640 ft to (160 km) 99.4 mi |
| Measurement Time |
User-defined (smart link); with real-time measurement function |
| Linearity |
≤0.05dB/dB |
| Loss Threshold |
0.01dB |
| Loss Resolution |
0.001dB |
| Distance Resolution |
(0.001 m) 0.39 in |
| Sampling Resolution |
Minimum (0.025 m) 9.84 in |
| Sampling Point |
Maximum 128,000 points |
| Distance Accuracy |
± (3.28 ft (1 m) + measuring distance × 3 × 10⁻⁵ + sampling resolution) |
| Internal Visual Source |
10 mw, CW/2Hz |
| Stable Laser Source |
>-5 dBm |
| Data Storage |
80,000 groups of curves |
| Interface |
3 USB ports |
| Display |
7-inch capacitive touchscreen |
| Battery |
7.4V/6.6Ah lithium battery, continuous 8-10 hours |
| Accessories |
Main unit, 8.4V power adapter, lithium battery, FC adapter, USB cord, user guide, CD disk, carrying case |
| Options |
SC/ST, bare fiber adapter |
| Operating Temperature |
-4 °F to +122 °F (-20 °C to +50 °C) |
| Dimension |
9.06 in × 7.28 in × 2.76 in (23 cm × 18.5 cm × 7 cm) |
| Weight |
3.3 lbs (1.5 kg) |
