| Emitter Type |
Laser |
| Safety Class |
Class 1 F D A 21 CFR 1040.10 and 1040.11, IEC |
|
60825 to 1: 2007-03 |
| Fiber Type |
Single-mode |
| Available Wavelengths |
FS200 to 50: 1510 ±20 nm |
|
FS200 to 100: 1310/1550 ±20 nm |
| Wavelength Tolerance |
±20 nm |
| Dynamic Range (SNR=1) b |
32/30 dB @1310/1550 nm |
| Event Dead Zone c |
2.62 ft (0.8 m) |
| Attenuation Dead Zone d |
(11.81 ft 3.6 m) |
| Pulse Widths |
3, 5, 10, 20, 30, 50, 100, 200, 300, 500 ns; |
|
1, 2, 3, 10 µs |
| Range Settings |
820 ft to 1.49 mi (250 m to 240 km) |
| Data Points |
Up to 2,300,000 / 1.96 in (5 cm) data-spacing |
| Data Spacing |
52.49 ft (16 m) |
| Group Index Of Refraction |
1.4000 to 1.7000 |
| Distance Uncertainty (m) |
± 3.28 ft (1) + 0.005% x distance + data point spacing) |
| Linearity |
±0.05 dB/dB |
| Trace File Format |
Telcordia SR-4731 Issue 2 |
| Trace File Storage Medium |
4 GB internal memory (>1000 traces); |
|
External USB memory stick |
| Data Transfer to PC |
USB cable or Wi-Fi (option) |
| Standard OTDR Modes |
SmartAuto, Expert, Real Time |
| Display Modes |
LinkMap Summary, LinkMap Events, Trace |
| Real-time Refresh Rate |
Up to 4 Hz |
| Live Fiber Protection |
No OTDR damage with input power ≤ +3 dBm |
|
for wavelength(s) in range 1260 to 1675 nm |
| Live Fiber Detection |
Reports live fiber with input signal ≥ to 35 dBm |
|
for wavelength(s) in range 1260 to 1675 nm |
| Power |
Rechargeable Li-Ion or AC adapter |
| Battery Life |
>12 hours, Telcordia test conditions |
| Display |
Color touchscreen 4.3 in LCD, 480 x 272, backlit |
| USB Ports |
1 host; 1 micro-USB function |
| Blue Tooth (Optional) |
Compatible with Windows PC, Apple iOS, Android |
| Calibrated Wavelengths |
1310, 1490, 1550, 1625, 1650 nm |
| Detector Type |
InGaAs, 2 mm diameter |
| Measurement Range |
+23 to -50 dBm |
| Tone Detect Range |
+3 to -35 dBm |
| Wavelength ID Range |
+3 to -35 dBm |
| Accuracy e |
±0.25 dB |
| Resolution |
0.01 dB |
| Measurement Units |
dB, dBm or Watts (nW, µW, mW) |
| WiFi (Optional) |
IEEE 802.11 / WLAN |
| Operational Temperature |
14 ℉ to 122 ℉ (-10 °C to +50 °C), 0 to 95 % RH (non-condensing) |
| Storage Temperature |
-40 ℉ to 158 ℉ (-40 °C to +70 °C), 0 to 95 % RH (non-condensing) |
| Size (In Boot) |
3.38 in x 6.29 in x 1.69 in (8.6 cm x 16 cm x 4.3 cm) |
| Weight |
0.88 lb (0.4 kg) |
