| Humidity |
95% |
| Communication Network |
Start topology |
| LoRaWAN Protocol |
Class A, class B, class C |
| Working Frequency |
EU433,CN470-510,CN779-787 |
| Communication Distance |
16,404.2 ft (6km) |
| Local Storage |
32G TF card |
| Communication Bandwidth |
125kHz,250kHz,500kHz |
| RX Sensitivity |
Max -140dbm @LoRa ; -70dbm @WIFI |
| Communication Bandwidth |
125kHz,250kHz,500kHz |
| Channels |
8 upstream channel,1 downstream channel |
| Speed |
Link adaptive speed |
| Work Mode |
Support different frequency and same frequency |
| Report to Server |
3G/4G, Wired network |
| Wireless Management |
WIFI management and upgrade |
| Local Storage |
32G TF card |
| LoRa Antenna, Interface |
N-type female, LoRa fibre-glass antenna ,2dBi gain |
| 4G Antenn,Interface |
N-type female, 4G fibre-glass antenna,3dBi gain |
| WIFI Antenna,Interface |
N-type female,2.4G fibre-glass antenna,3dBi gain |
| GPS Antenna, Interface |
-type female,GPS fibre-glass antenna,4dBi gain |
| Power Way |
AC220,POE,Solar power |
| POE Standard |
IEEE802.3af/IEEE802.3at |
| Average Current |
≤140mA@12V |
| Transmit Current |
≤550mA@12V |
| Receive Current |
≤420mA@12V |
| Operating Temperature |
-40 °F to 185 °F (-40 ℃ to 85 ℃) |
| Storing Temperature Range |
-40 °F to 257 °F (-40 ℃ to 125 ℃) |
| Size |
11.4 in × 8.56 in × 4.53 in (28.94 cm × 21.75 cm × 11.5 cm) |
| Weight |
95.24 oz (2700 g) |
