Description
Technical Specifications
| Application | LoRaWAN solutions, water meter AMR system |
| Frequency | EU433 / RU864 / IN868 / EU868 / US915 / AU915 / KR923 |
| Protocol | LoRaWAN Standard |
| Power Supply | DC 12V or Solar Power Supply |
| Transmission Range | Urban: 3.11 miles – 4.97 miles (5 km – 8 km) Rural: > 9.32 miles (> 15 km) |
| Ingress Protection | IP67 / NEMA-6 industrial-grade enclosure with cable glands |
| Backhaul | Wi-Fi, LTE, and Ethernet |
| GPS | Internal / External |
| Surge Protection | PoE (802.3af) |
| Dual LoRa Concentrators | Up to 16 channels |
| Power Supply Monitoring | Supports DC 12V or Solar Power Supply with Electricity Monitoring (Solar Kit optional) |
| Dying-Gasp | Optional Built-in Network Server OpenVPN Software and UI sit on top of OpenWRT LoRaWAN 1.0.3 LoRa Frame filtering (node whitelisting) MQTT v3.1 Bridging with TLS encryption Buffering of LoRa frames in Packet Forwarder mode in case of NS outage (no data loss) Full duplex (optional) Listen Before Talk (optional) Fine timestamping (optional) |
