| Processor |
Quad-core 1.5GHz, 64-bit ARM Cortex-A53 |
| Power Supply |
802.3af PoE Input, 12 VDC with M12 connector |
| Working Current |
Typical 3.6W, Max 4.8W |
| Radio Chip |
SX1302 |
| Frequency |
AU915 |
| Tx Power |
27 dBm Max |
| Protocol |
V1.0 Class A/Class B and V1.0.2 Class A/Class B/Class C |
| Ports |
1 × 10/100/1000Mbps RJ45 (PoE PD supported), auto MDI/MDIX |
| Standard |
IEEE 802.11 b/g/n, 2.4 GHz |
| VPN Tunnel |
DMVPN/IPsec/OpenVPN/PPTP/L2TP/GRE |
| Processor Feature |
Quad-Core 64-bit Processor: powerful performance |
| Traffic Handling |
Semtech SX1302: Remarkable ability to handle traffic loads |
| Internet Connections |
Ethernet, Wi-Fi, or 3G/4G backup |
| LoRaWAN Protocol |
Flexible network accessing, wide connection |
| Waterproof |
IP67: Designed for the outdoors, fearless of wind and rain |
| Network Server |
Connect to Server via TCP/HTTP/MQTT |
| Capacity |
Up to 2000 end nodes |
| Antenna |
2 × Antenna connector |
| Ethernet |
1 × 10 / 100 / 1000Mbps with PoE In |
| Reset |
Reset to factory settings |
| DC Power |
M12 connector |
| SIM Slot |
1 × Mini-SIM (2FF) |
| Micro SD |
SD card slot |
| Waterproof Specifications |
IP67: Designed for the outdoors, fearless of wind and rain |
| Power Input |
802.3af PoE Input, 12 VDC with M12 Connector |
| Application Areas |
Smart City, Smart Agriculture, Smart Energy, Smart Industry, Smart Mine, Instrument |
| Operating Temperature |
-40°F to 158°F (-40°C to +70°C) |
