| CPU |
Cortex-A7 |
| Main Frequency Size |
528 MHz |
| Internal Storage |
518 MB |
| Flash Memory |
8 GB |
| Built-in |
Hardware watchdog, a timer |
| Ethernet |
10/100M adaptive dual-network port |
| PDA |
BLE4.2 |
| Communication Mode |
4G Cat.1 |
| Wireless System |
LoRa full duplex |
| LoRa Service Frequency |
Domestic: 470 MHz to 510 MHz (multi-band optional: IN865/RU864/EU868/US915/AU915/ KR920/AS923) |
| 4G Operating Frequency |
LTE-FDD: B1, B3, B5, LTE-TDD: B34, B38, B39, B40, B41 |
| LoRa Receive Channel |
8-way 125 KHz SF adaptive (5 to 12) channel, 1-way 125 or 250 or 500 bandwidth standard LoRa channel |
| LoRa Transmitting Power |
22 dBm |
| The LoRa Reception Sensitivity |
-141 dBm (SF12 & BW 125 KHz) |
| 4G Communication Protocol |
TCP/UDP/MQTT (Software Configurable) |
| LoRa Communicating Protocol |
Rapper protocol or standard LoRaWAN protocol |
| Data Format |
Transmission, TLV, JSON (software urable) |
| 4G Data Rate |
LTE-FDD (Mbps) 10 (Downside) / 5 (Up), LTE-TDD (Mbps) 8.9 (Downside) / 3 (Up) |
| LoRa Data Rate |
300 bps to 62.5 kbps |
| Power Supply Mode |
External power supply, waterproof connector or POE |
| Service Voltage |
DC 9 V to 24 V |
| The Power of the Machine |
3 W |
| Levels of Protection |
IP67 |
| Way to Install |
Hold the pole installation |
| Work Environment |
Temperature: -40 °F to 158 °F (-40 °C to 70 °C), relative humidity: 95% RH (no condensation) |
| Product Size |
9.25 in × 8.38 in × 2.83 in (23.5 cm × 21.3 cm × 7.2 cm) |
