Description
Features
- High-Performance Industrial-Grade Solution:
- Utilizes NXP A53 quad-core CPU and Semtech SX1302 chip
- Supports full duplex uplink and downlink data transmission
- Features 8 channels for wide coverage and low power consumption
- Industrial Grade Design:
- IP67 waterproof and dustproof, suitable for various application scenarios
- Compatible with PoE power supply
- Oversized Connections:
- Supports access for up to 2000 nodes
- Compatibility with Third-Party Devices:
- Supports standard LoRaWAN protocol terminal device access for complete data collection and command forwarding
- Compatible with mainstream network servers: Link WAN, Tencent Cloud, TTI, Chirp Stack, etc
- Variety of Installation Methods:
- Easy installation options: supports wall mount and pole mount
- Suitable for Various Application Scenarios:
- Ideal for smart energy, smart agriculture, smart parking, smart buildings, hydraulic management, streetlight monitoring, disaster management, and industrial automation
Technical Specifications
| Humidity | 0% to 95% |
| Processor | Quad-core 1.5 ghz, 64-bit arm cortex-a53 |
| Memory | 8Gb flash, 512mb ddr4 ram |
| Communication Distance | Over 9.32 mi (11 km) radius |
| Backhaul Connectivity | 3G/4G/eth |
| GPS | Supports |
| Ingress Protection | Ip67 |
| Flash | 8 Gb emmc |
| Software | |
| Network Protocol | Pppoe, snmp v1/v2c/v3, tcp, udp, dhcp, ddns,http, https, dns, arp, sntp, telnet, ssh, mqtt, etc. |
| VPN Tunnel | Openvpn/IPSEC/PPTP/L2TP/GRE/DMVPN |
| Connectivity | |
| Ethernet | 1 x 10/100/1000 Mbps |
| Cellular (Optional) | 1 x SIM Slot |
| Wi-Fi (Optional) | Ieee 802.11 b/g/n |
| Console | 1 x Console (RJ45) |
| GPS + GLONASS | Yes |
| LoRaWAN | |
| Frequency | 433/868/902/915/470/923/920 |
| Channel | 8 |
| Sensitivity | -140Dbm sensitivity @292bps |
| Output Power | 27Dbm max |
| Protocol | V1.0 Class A/Class C and V1.0.2 Class A/Class C |
| Operating Temperature | -40 °F to 158 °F (-40 °C to 70 °C) |
| Size | 9.84 in × 6.77 in × 3.62 in (25.0 cm × 17.2 cm × 9.2 cm) |
