| LoRaWAN Compatibility |
Supports Class A or B or C modes |
| Channel Support |
8 or 16 channels for uplink; 1 to 2 channels for downlink |
| Duplex Mode |
Optional half-duplex or full duplex |
| Output Power |
Max 25 dBm |
| Power Supply Options |
Supports PoE, external DC, internal backup, solar expansion |
| Battery Backup |
Supports full load for more than 4 hours |
| Antenna Interface |
4G, Wi-Fi, and LoRa: N to J female connectors |
| Protection |
IP67 rated for outdoor use, 10KV lightning protection |
| Frequency Bands |
434MHz, 470MHz, 510MHz, 868MHz, 915MHz |
| Interfaces |
USB debugging, 10 or 100M Ethernet, 4G wireless (WCDMA or TD-LTE or GPRS or EDGE) |
| LoRa Sensitivity |
-141 dBm @ 300 bps, SF12, BW 125 KHz |
| Max LoRa Output Power |
+27 dBm |
| CPU |
ARM Cortex-A53 1.2 GHz |
| Working Temperature |
-40 °F to 167 °F (-40 °C to 75 °C) |
| Antenna Size |
8.26 in x 7.87 in x 3.34 in (21 cm x 20 cm x 8.5 cm) |
| Weight |
7.40 oz (210 g) |
