Description
Technical Specifications
| Operating Humidity | 0% to 95% |
| Power Supply | 42 VCD to 57 VDC |
| Frequency | 2.400 GHz to 2.4835 GHz |
| RX Sensitivity | -95 dBm (Min) |
| TX Power | 20 dBm (Max) |
| Operation Channels | 2.4GHz: 1-13 |
| Card | SX1301 mini PCIe card (connects maximum of two) |
| Channels | 8 Channels (Optional: 16 channels) |
| Sensitivity | -139dBm (Min) |
| Frequency Range | EU433, CN470, EU868, US915 , AS923, AU915, KR920, IN865 |
| WIFI Operation Channels | 2.4GHz: 1-13 |
| Power Consumption | 12W (Typical) 20dBm (Max) |
| ETH | RJ45 (10/100Mbps) |
| Antenna | 5 N-Type connectors |
| Ingress Protection | IP67 |
| Enclosure Material | Aluminum |
| Operating Temperature | -22 °F to 131 °F (-30 °C to 55 °C) |
| Charging Temperature | -40 °F to +185 °F (-40 °C to +85 °C) |
| Dimension | 8.66 in x 8.66 in x 4.09 in (22.0 cm x 22.0 cm x 10.4 cm) |
| Weight | 6.94 lbs (3.15 kg) |
