| Specification Name |
Specification description |
| Network Type |
4G (full Netcom module, user can choose support/non-support model) |
| Antenna Interface |
4G: N-J female connector; Wi-Fi: N-J female connector; LoRa: N-J female connector |
| Button |
RESET button (restore to factory settings) |
| Ethernet Interface |
1 X WAN 10/100Mbps adaptive ethernet interface |
| Power Supply |
AC 110 277 V, supports POE (power over Ethernet) |
| Working Power Consumption |
≤ 20 W (affected by network signal strength and type) |
| Relative Humidity |
≤ 95 % (no condensation) |
| 4G Working Frequency |
FDD LTE: B1/B3; TDD LTE: B38/B39/B40/B41; TDSCDMA: B34/B39; CDMA2000 1x/EVDO: BC0; GSM: 900/1800 MHz |
| Transmission Speed |
LTE-FDD: Max 100 Mbps (DL), Max 50 Mbps (UL); LTE-TDD: Max 61 Mbps (DL), Max 18 Mbps (UL); SCDMA-TD: Max 4.2 Mbps (DL), Max 2.2 Mbps (UL); CDMA: Max 5.4 Mbps (DL), Max 14.7 Mbps (UL); GPRS: Max 85.6Kbps (DL), Max 85.6Kbps (UL) |
| Transmit Power |
FDD LTE: 23 dbm ± 2db; TDD LTE: 23dbm±2db; TDSCDMA: 24d bm +1/-3db; GSM 900MHz: 33 dbm ± 2 db; GSM 1800 MHz: 30dbm ± 2 db |
| Receiving Sensitivity |
FDD B1: -97dBm (20M); FDD B3: -96 dBm (20 M); TDD B38: -94 dBm (20 M); TDD B39: -94 dBm (20M); TDD B40: -94 dBm (20 M); TDD B41: -93.5 dBm (20 M); TDSCDMA B 34: -110 dBm; TDSCDMA B39: -110 dBm; CDMA BC0: -108 dBm; GSM 900: -110 dBm; GSM 1800: -109 dBm |
| Wi-Fi Standard and Frequency Band |
IEEE802.11b/g/n standard |
| Theoretical Bandwidth |
Up to 300 Mbps |
| Transmit Power (Wi-Fi) |
20 dbm |
| System – CPU |
32 bit |
| System – FLASH |
128 M |
| System – DDR2 |
128 M |
| Working Temperature |
−40°F to +176 °F (-40 ºC to +80 ºC) |
| Storage Temperature |
−40 °F to + 185 °F (-40 ºC to +85 ºC) |
| Dimension |
8.87 in × 8.87 in × 3.12 in (22.53 cm × 22.53 cm × 7.93 cm) |
