| Protection Grade |
IP67/NEMA-6 Industrial protection grade enclosure (with cable interface) |
| Power Over Ethernet |
PoE (802.3af) + Surge protection |
| LoRa Concentrator |
Dual LoRa concentrator, can contain up to 16 channels |
| Connectivity |
Supports Wi-Fi, LTE, and Ethernet |
| GPS |
Yes |
| Power Supply |
Supports DC 12V or solar power supply with power monitoring (solar energy kit optional) |
| Antenna |
Built-in antenna applied (external antenna if used) |
| Power Off Alarm |
Optional |
| Gateway Function |
Built-in LoRa server |
| OpenVPN Client |
Supported |
| Software |
OpenWRT-based user interface |
| Protocol |
Based on LoRaWAN 1.0.3 protocol |
| LoRa Frame Filtering |
Node whitelist |
| MQTT |
v3.1 bridge with TLS encryption |
| Data Handling |
Support for buffer in packet mode, no data loss when NS is interrupted |
| Half Duplex |
Optional |
| Time Stamp |
Optional |
| Type |
Customizable |
| System Composition |
LoRaWAN module, gateway, application services |
| Accessories |
Antenna, power supply, bracket, etc. |
| Features |
Low power consumption, low cost, long communication distance |
| Frequency |
433 MHz to 928 MHz |
| Communication Distance |
Greater than 9.32 miles (15 km) |
| Communication Support |
Wi-Fi, LTE, and Ethernet |
| Waterproofing Grade |
IP67, NEMA-6 industrial protection grade housing |
