Description
Technical Specifications
| Operating Frequency | 125KHZ |
| Communication Speed | 106Kbit/s |
| Baud Rate | 9600Kbit/s |
| Power Supply | DC 5V (± 5%) |
| Current Consumption | <100MA |
| Effective Operating Distance | 100mm |
| Interface | RS232 or R232 or USB |
| Expansion | I / O port free |
| Status Indication | 2 LEDs (one power LED, 1 status indicator) or a BUZ |
| Operating Temperature | 14°F to 158°F (-10°C to 70°C) |
| Storage Temperature | -4°F to 176°F (-20°C to 80°C) |
| Maximum Operating Humidity | 0% to 95% relative humidity |
| Support | TK4100 or EM4200 or EM4001, etc. compatible format IC card (64bits and Manchester coding) |
