| Visual Fault Locator (VFL) |
10 mW; 2.5 mm universal connector |
| Display |
3.5-inch high-definition touchscreen |
| Self-Calibration Function |
Supported |
| Measurement Modes |
Real-time, average, automatic |
| Dynamic Range |
20 dB |
| Test Range |
328 ft to 49.7 mi (100 m to 80 km) |
| Wavelength |
1550 nm (±20 nm) |
| OTDR/OLS Connector |
SC/UPC |
| Pulse Width |
5 ns to 20 µs |
| Attenuation Dead Zone |
39.4 ft (12 m) |
| Event Dead Zone |
<8.2 ft (<2.5 m) |
| Sampling Points |
20,000 |
| Relative Humidity |
<90% |
| Operating Temperature |
32°F to 122 °F (0°C to 50°C) |
| Storage Temperature |
-4°F to 158 °F (-20°C to 70°C) |
| Dimensions (H x W x D) |
4.96 in x 3.15 in x 1.46 in (12.6 cm x 8 cm x 3.7 cm) |
| Weight |
7.05 oz (200 g) |
