| The Absolute Value of Harmonic Power |
Depends on current range and voltage nominal value |
| Display Type |
Analog and Digital |
| Phase |
Three Phase |
| AC Current (A) |
0 to 3000.0 A |
| AC Voltage (V) |
0.00 V to 1000 V |
| Frequency (Hz) |
45 Hz to 65 Hz |
| Active Power (W) |
0.0 W to 9000 kW |
| Apparent Power (VA) |
0.0 VA to 9000 kVA |
| Reactive power (VAr) |
0.0 VAR to 9000 kVAR |
| Power factor |
-1 to +1 |
| Phase Angle (°) |
0.0° to 360° |
| Flicker Pst(1min), Pst, Plt) |
0.00 to 20.00 |
| Voltage Unbalance |
0.0 to 20.0% |
| Current Unbalance |
0.0 to 20.0% |
| Harmonic Voltage Relative Value (%F) |
0 to 100.0% |
| Harmonic Voltage Relative (%R) |
0 to 100.0% |
| The Absolute Value of the Harmonic Voltage |
0 to 1000 V |
| Voltage THD |
0 to 100.0% |
| Harmonic Current Relative (%F) |
0 to 100.0% |
| Harmonic Current Relative Value (%R) |
0 to 100.0% |
| The Absolute Value of the Harmonic Current |
40 to 3000 A |
| Current THD |
0 to 100.0% |
| Harmonic Power Relative Value (%f or %r) |
0 to 100.0% |
| Power THD |
0 to 100.0% |
| Frequency |
0 to 2500 Hz (1 to 50 th harmonic) |
| Phase |
0 to 360o |
| Half-Cycle Rms Voltage |
0 to 200 % of nominal voltage |
| Half-Cycle Rms Current |
3000 A |
| Event Duration |
Mm : ss :mmm |
| Standard Accessories |
3000 4A flexible probes, 5 test cable 1 cores, 1 USB data cable, 1 set of power adapter |
| Optional Accessories |
6000 4A flexible probes |
| Dimensions |
18.30 in x 15.15 in x 6.37 in (46.5 cm x 38.5 cm x 16.2 cm) |
| Fuselage Weight |
4.29 lb. (1.95 kg) |
