Description
Technical Specifications
| Bluetooth Version | BLE 5.0 |
| Work Mode | IBeacon Eddystone |
| Battery Model | CR2032 Coin battery, 3.0Vdc, 1 pc |
| Operation Frequency | 2400-2483.5MHz Programmable |
| Frequency Error | +/- 20KHz |
| Modulation | Q-QPSK |
| Standby Current | 46uA Depends on duty cycle/broadcasting frequency |
| Broadcasting Frequency | 2S Duty cycle |
| Output Power | 0 dBm Default setting, programmable |
| Receiving Sensitivity | -93dBm High gain mode |
| Transmission Distance | 30 meters BER<0.1%, Open space |
| Antenna | 50ohm On board/ PCB Antenna |
