| System |
|
| CPU |
64-bit, quad-core |
| RAM |
DDR4, 2GB (8GB Option) |
| Flash |
eMMC, 16GB (128GB Option) |
| NPU |
512MAC, up to 1 TOPS |
| GPU |
Mali-G52, OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1 |
| Cellular Interfaces |
|
| Antenna |
4 × 50 Ω SMA Female (5G Version) |
| Connector |
2 × 50 Ω SMA Female (4G Version) |
| SIM Slot |
1 × Micro SIM (Dual SIM, Option) |
| ESD Protection |
15KV |
| Ethernet Interface |
|
| Ports |
4 × RJ45 (1-WAN, 3-LAN or 4-LAN configurable) |
| Data Rates |
10/100/1000 Mbps (Auto-Sensing), Auto MDI/MDIX |
| ESD Protection |
1.5KV |
| Serial Interfaces |
|
| Connector |
Terminal block, 3.5 mm female socket |
| Ports |
2 × RS232 (1-Debug, 1-Shared via RS485), 6 × RS485 |
| Baud Rate |
300bps to 23400bps |
| ESD Protection |
8KV for RS232, 15KV for RS485 |
