| Phase |
Three Phase |
| Protection |
Over Voltage / Over Current / Overload |
| Application |
Computer / Communication / Server… |
| Wave Form |
Pure Sine Wave |
| Input Voltage |
208V / 220V / 230V / 240V |
| Communication |
RS485 / MODBUS |
| Battery Type |
Lead Acid Battery |
| Frequency |
40 to 70 Hz |
| Display |
LED Display |
| Transfer Time |
0 ms |
| Backup Time |
5 minutes to 15 minutes |
| Protection Features |
Short Circuit / Over Temp / Overload / Overvolt |
| Machine Architecture |
Double Conversion Online UPS |
| Phases |
Three-phase input / single-phase output |
| Input Lines |
Three-phase four wire + protective ground or single-phase three-wire (zero/live wire + protected ground) |
| Rated Voltage |
208V / 220V / 230V / 240V AC |
| Input Frequency |
50Hz / 60Hz |
| Input Voltage Range |
Phase voltage of 90 ~ 300 VAC ±5 VAC / Line voltage: 156 to 520VAC ±5VAC |
| Bypass Voltage |
115 to 285 VACS × (1 ± 3%) |
| Input Power Factor |
≥0.99 |
| Battery Voltage |
192V / 240V (optional) |
| Backup Time (Half / Full Load) |
Standard: Half load ≥ 6 minutes, full load ≥ 2 minutes; Long acting: depends on external battery |
| Maximum Impulse Current |
<150% of rated current |
| Battery Charge Time |
Standard model: charge to 90% in 5 hours; Long acting: depends on external battery pack capacity |
| Output Mode |
Single-phase 2 cables + protection ground |
| Output Voltage |
220V / 230V / 240V AC ±2% (inverter output) |
| Output Frequency |
50Hz / 60Hz ±0.5% |
| THDV% |
Sine wave THDV < 2% (linear load); sine wave THDV < 7% (nonlinear load) |
| Output Power Factor |
0.9 |
| Transfer Time |
Mains to Battery Mode: 0 ms |
| Overload Capacity |
Mains/Battery (240VDC): 105% to 125% for 10 minutes, 126% to 150% for 1 minute, >150% 100ms; Battery (192VDC): 105% to 125% for 1s, >126% for 100ms |
| Size |
21.85 in × 9.37 in × 20.80 in (55.5 cm × 23.8 cm × 52.8 cm) |
| Weight |
33.07 Lb to 59.52 Lb (15 kg to 27 KG) |
