Description
Features
- Multi-back haul options
- Lorawan/GPS/Wi-Fi/BLE
- IP66 waterproof casing
- High device capacity
- Global frequency bands
Technical Specifications
| Indicator LED’s | 1) Power LED on when powered 2) Network led on when connected 3) Card indicator |
| Lora Concentrator Engine | Semtech SX1302 |
| Power Supply | POE & 5 V adapter |
| Input Voltage Range | 4.5 V to 5 V |
| System | Linux |
| Current | 350mA at 5 V |
| TF Card | Up to 128GB |
| Antenna | Wi-Fi antenna, LTE antenna, optional Bluetooth, zigbee, GPS |
| Waterproof Level | IP66 |
| Reset Button | Reset button inside gateway. press for more than 5 seconds to restore factory settings |
| ROM | Emmc Up to 128GB |
| Power Adapter | 100 to 240 V, 50 to 60 HZ, output is 5 V or 2 A |
| CPU | PX30 Quad-core cortex-A35 |
| RAM | 2 GB |
| Working Temperature | 14 °F to 158 °F (-10 °C to 70 °C) |
