Description
Features
- 10.1-inch capacitive 10-point touch screen
- Quad-core RK3568 processor with Android 11 OS
- 5G Wi-Fi, RJ45 with POE, and Bluetooth 5.4 connectivity
- USB Type-C, OTG, SD card, and serial interfaces
- Dual 2W speakers, wide-angle 2.0MP camera, LED light bar
Technical Specifications
| Model Variants | ATPOITB-132 (A), (B), (C), (D) |
| Diagonal Size | 10.1 inch (LCD) |
| Resolution | 1280 × 800 pixels |
| Aspect Ratio | 16:10 |
| Luminance | 250 nits |
| Touch Points | 10-point touch |
| CPU | (A) RK3288 Quad Core Cortex-A17(B) RK3399 Dual Core Cortex-A72 + Quad Core Cortex-A53(C) RK3566 Quad Core Cortex-A55(D) RK3568 Quad Core Cortex-A55 |
| RAM | (A) 2 GB(B/C/D) 2 GB (Optional 4 GB) |
| ROM | (A) 16 GB(B/C/D) 16 GB (Optional 32 GB or 64 GB) |
| Operating System | (A) Android 5.1 / 8.1 / 10.0(B) Android 7.1 / 10.0(C/D) Android 11 |
| Wi-Fi | (A) 802.11 b/g/n(B) 802.11 a/b/g/n/ac(C/D) 802.11 b/g/n |
| Bluetooth | Bluetooth 4.2 |
| USB | (A) USB 2.0 Host(B) USB 3.0 Host(C/D) USB 2.0 Host, USB 3.0 Host |
| Serial Port | (A) USB for Serial (RS232 level), Optional USB Host(B/C/D) USB for Serial (TTL level) |
| Micro USB | Micro USB OTG |
| Power Port | DC Power Input |
| Video Format | MPEG-1, MPEG-2, MPEG-4, H.265, H.264, VC-1, VP8, etc. (up to 4K) |
| Photo Format | JPEG (A)JPEG / PNG (B/C/D) |
| Camera | Routine angle 5.0 MP |
| Speaker | 2 W × 2 |
| VESA Mount | 75 mm × 75 mm |
| Certificates | CE / FCC |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Dimensions | 10.21 × 7.02 × 1.13 in (259.36 × 178.36 × 28.70 mm) |
