Description
Technical Specifications
| GPU | Cortex M0 at 250 MHz, 16TFLOPS (INT8) |
| CPU | 4 cores A55 at 1.5 GHz + Coresight + GiC600 |
| Memory | 8 GB 64bit LPDDR4 |
| Storage | 64 GB eMMC 5.1 flash + TFcard |
| Video Encode | 8 x 1080p at 30 fps (H.265) |
| Video Decode | 16 x 1080p at 30 fps (H.265) |
| Network | 2 x 10 or 100 or 1000 BASE-T Ethernet (RJ45)
1 x WIFI (Optional) 1 x 4G or 5G (Optional) |
| Expansion | 1 x M.2 2280 (for NVME SSD of PCEIX1)
1 x Mini PCIE (Module of PCIE Signal) 1 x Mini PCIE (Module of USB Signal) 1 x TF card slot 1 x SIM card slot |
| COM | 1 x RS485 (4PIN phoenix, default, compatible with RS422) |
| CAN | 1 x CAN (10PIN phoenix, compatible CAN_FD) |
| USB | 2 x USB 3.0 (Type A)
1 x USB 2.0 OTG (Type C) |
| GPIO | 4 x GPIOs (10PIN phoenix) |
| LED | 1 x Red LED (Power indication)
1 x Green LED (Power indication control by GPIO04) |
| Power Supply | DC_IN 12V (1 x 2PIN phoenix + 1 x DC005, 12V or 40W adapter is equipped by default) |
| Material | Aluminum |
| Color | Iron gray |
| Operating Temperature | -4°F to 122°F (-20°C to 50°C) |
| Size | 7.87 in (L) x 4.92 in (W) x 1.61 in (H)
(200 mm (L) x 125 mm (W) x 41 mm (H)) |
| Weight | 3.30 lb (1.5 kg) |
