| Display Type |
Digital Only |
| Accuracy Class |
0.2%FS ±10 digits |
| Test Current |
20 A, 10 A, 5 A, 1 A, 0.1 A, 10 mA, 1 mA |
| Resistance Range |
10.0 μΩ to 1000.0 KΩ |
| Sample Type |
Optional Cu (Copper), Al (Aluminum), Fe (Iron), Au (Gold), Ag (Silver) |
| Touch and Color Screen |
Yes |
| Printer |
Yes |
| Data Storage |
800 Group |
| Detection Method |
Four-wire test method |
| Power |
DC 14.6 V, 12000 mAh Lithium Battery |
| Mobile App and PC |
Yes, with USB cable connection |
| Working Temperature & Humidity |
14 °F to 104 °F (-10 °C to 40 °C); 70% RH |
| Dimensions |
10.92 in x 8.95 in x 6.02 in (27.72 cm x 22.75 cm x 15.3 cm) |
