Description
Overview
Asset Track Pro Edge Computing Raspberry Pi Gateway Support Multiple Industrial are edge computing gateways launched by IOT Router Chengdu. With its rich hardware interfaces, drag-and-drop programming method, Zero Code design concept, convenient remote management and other characteristics, It can quickly, flexibly, accurately and efficiently respond to various IoT industry needs. Edge8000 abstracts complex hardware interfaces, different industrial network protocols, etc. into Nodesone by one. Users can use these Nodes flexibly to replace the traditional complex and inefficient coding process by dragging and connecting. Really let customers focus on business logic and quickly create their own gateway equipment. The mission of Edge8000 is to continuously develop new Nodes to serve industry customers to adapt to the fragmentation of IoT industry needs.
Technical Specifications
| Network Protocol | MQTT or HTTP or TCP or UDP or WEBSOCKET |
| Edge Computing | Support drag and drop programming
Support zero-code development Support JavaScript development |
| Data Storage | Support TSDB (Time Series Databases) |
| CPU | ARM Cortex-A72 4 X 1.5G |
| Storage | 1G + 8G |
| Real Time Clock | Support |
| WAN | 1 x 1000 or M Support DHCP Client |
| LAN | 1 X 100 or M Support DHCP Server |
| USB | 2 X USB |
| Rated Voltage | 2 GB or 4 GB or 8 GB |
| Industrial Agreement | Support multiple industrial protocols (Developing) |
| RS485 | 2 |
| RS232 | 1 |
| DO (Hardware) | 4 X Relay Output (10A or 250 V AC 30 VDC) |
| DI (Hardware) | 4 X Relay Input (Wet & Dry nodes) |
| AO (Hardware) | 4 X Analog Output (4 mA to 20 mA, 12 bit precision) |
| AI (Hardware) | 4 X Analog Input (4 mA to 20 mA, 12 bit precision) |
| LED (Hardware) | Support DO or DI status indication (customizable) |
| OPS | Support remote configuration or upgrade or management |
| VPN | Support intranet penetration support PLC remote upload and download (network port) |
