Description
Features
- Dual Network Support, NB-IoT and LTE-M
- Multiple Power Options, 8500 mAh battery
- Waterproof & Durable, for outdoor use
- BLE 5.0 Compatibility, Over-the-Air Updates
Technical Specifications
| BLE Version | BLE 5.0 |
| Material | ABS/PC |
| Protocol | HTTPs, UDP, MQTT |
| Waterproof Rating | IP67 |
| OTA | Yes |
| Power Supply | 1. ER26500 8500mAh battery 2. Type-C rechargeable battery 3500mAh |
| Network | NB-IoT, LTE-M |
| Battery Life | 1. ER26500 8500mAh: Up to 10 years 2. Rechargeable battery: Up to 3 years per charge |
| LTE Band | Cat-M1: B1, B2, B3, B4, B5, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B66 Cat-NB1/NB2: B1, B2, B3, B4, B5, B8, B12, B13, B17, B18, B20, B25, B26 |
| Scanning Ability | Max 32 devices per scanning |
| Operating Temperature | -40 °F to 158 °F ( -40°C to +70°C ) |
| RX Sensitivity | -108dBm @1Mbps, 0.1% BER -115dBm @125kbps, 0.1% BER |
| GNSS (Optional) | GPS / Glonass / Beidou |
| Weight | 7.55 oz (214 g) |
| Size | 3.54 in × 1.97 in × 1.65 in ( 90mm × 50mm × 42mm ) |
