| Frequency Range |
9 kHz to 6.3 GHz |
| Frequency Accuracy |
± 0.01 ppm |
| Level Accuracy |
± 1.5 dB |
| Level Resolution |
0.1 dB |
| Power Supply |
AC 100 V to 240 V or 50 Hz to 60 Hz DC 12 V |
| Ambient Temperature |
32 ⁰F to 104 ⁰F (0 °C to 40 °C) |
| Wavelength Accuracy |
± 0.5 nm |
| Wavelength Data Output Interval |
1 nm |
| Screen Type |
5 in (12.7 cm) HD IPS capacitive touch screen |
| Maximum Input Safe Power |
25.7 dBm |
| Third Order Intermodulation Interception Point |
+12 dBm, typical value |
| Second Harmonic Suppression |
-75 dBc |
| Reference Level Range |
-130 dBm to +30 dBm |
| Spectrum Scanning Speed |
9 kHz to 6.3 GHz: 18GHz/s at 25 kHz9 kHz to 9 G or 20 G: 137GHz/s at 25 kHz |
| Real Time Spectrum Analysis Bandwidth |
Maximum 100 MHz |
| Demodulation Analysis Support Mode |
5G NR, LTE, NB-IoT, WCDMA, GSM, Vector signal |
| Dimension |
11.61 in x 8.86 in x 1.97 in (295 mm x 225 mm x 50mm) |
| Weight |
5.07 lb. (2.3 kg) |
