| Frequency |
13.56MHz |
| Protocol |
ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc. |
| Chips |
M1 card (S50, S70), CPU card, NFC tags, etc. |
| Range |
0.78 in to 1.57 in (2cm to 4cm) |
| GNSS |
GPS/AGPS, GLONASS, BeiDou; internal antenna |
| Display |
5.2” IPS FHD 1920×1080 |
| Touch Panel |
Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported |
| Keypad |
4 front buttons, 1 side button, 2 scan keys, 1 multifunctional key |
| CPU |
Cortex-A53 Quad-core 1.3GHz |
| RAM+ROM |
3GB+32GB |
| Expansion |
Supports up to 32 GB Micro SD card |
| Operating System |
Android 11 |
| Operating Temperature |
14°F to 122°F (-10°C to 50°C) |
| Storage Temperature |
-40°F to 158°F (-40°C to 70°C) |
| Humidity |
5% to 95%RH (Non-condensing) |
| Sealing |
IP67 |
| Drop Specification |
Multiple 5.9ft (1.8m) drops (at least 20 times) to the concrete across the operating temperature range |
| Tumble Specification |
1000 x 1.64ft. (0.5m) falls at room temperature |
| ESD |
±8KV air discharge, ±4KV conductive discharge |
| Dimension |
6.46in x 3.10in x 0.67in (164.2mm x 78.8mm x 17mm) |
| Weight |
<9.17 oz. (260g) |
