Description
Technical Specifications
| Frequency | 125 KHz |
| Type | Circuit Board |
| Baud Rate | 9600 |
| Interface | TTL level RS 232 |
| Working Voltage | DC 5 V |
| Working Current | <50 mA |
| Receive Distance | 0.78 in to 1.96 in (20 mm to 50 mm) |
| Humidity | 0 % RH to 95 % RH |
| Application | RFID |
| Operating Temperature | 14 °F to 158 °F (-10 °C to + 70 °C) |
| Storage Temperature | -4 °F to 176 °F (-20 °C to + 80 °C) |
| Wiring Size | 1.81 in X 1.25 in X 0.11 in (46 mm X 32 mm X 3 mm) |
| PCB Size | 1.51 in X 0.74 in X 0.35 in (38.5 mm X 19 mm X 9 mm) |
| Size | 1.81 in X 1.25 in (46 mm X 32 mm) |
| Weight | 0.35 oz (9 g) |
