Description
Technical Specifications
| Frequency | 125 KHz |
| Type | Reader module |
| Power Supply | DC 12 V |
| Working Current | 100 mA |
| Distance Of Transmission | WG 26 or 34≥100 M |
| Interface | Wiegand 26 or 34 |
| Read Range | 0 in to 3.93 in (0 mm to 100 mm) |
| Support Cards | EM 4100 TK 4100 |
| Indicators | Double Color LED (Red & Green) and Buzzer (“Red” means standby, “Green” means reader success) |
| Storage Temperature | -4 °F to 176 °F (-20 °C to + 80 °C) |
| Working Temperature | -14 °F to 158 °F (-10 °C to + 70 °C) |
| Cable Length | 180 mm ± 5 mm (7.09 in ± 0.20 in) |
| Weight | 0.705 oz (20 g) |
| Size | 2.01 in X 1.46 in X 0.04 in (51 mm X 37 mm X 1 mm) |
