| Certifications |
FCC, CE, RoHS, SRRC |
| Frequency Range |
840 MHz to 960 MHz, adjustable |
| Protocol |
EPC C1G2, ISO18000-6B/C |
| Frequency Band |
GB: 920 MHz to 925 MHz, 840 MHz to 845 MHz; FCC: 902 MHz to 928 MHz |
| Optional Frequency Band |
ETSI: 865 MHz to 868 MHz; JP: 916.8 MHz to 920.4 MHz; TW: 922.25 MHz to 927.75MHz |
| Communication Protocol |
COM |
| Reading Distance |
0 cm to 30 cm, adjustable |
| Antenna Gain |
OdBi |
| Working Mode |
Fixed frequency / frequency hopping optional |
| RF Output Power (Port) |
33 dBm ±1 dBm (MAX) |
| Recognizing Speed |
>400 times per s |
| Communication |
COM port or HID |
| RS232 |
Baud rate support: 9600, 19200, 115200 (default), 460800 optional |
| Material |
ABS |
| Power Supply |
USB power supply |
| Power Consumption |
15W (output power 33 dBm) |
| Working Humidity |
< 95 % at +77 °F (+25 °C) |
| Operating Temperature |
-4 °F to +140 °F (-20 °C to +60 °C) |
| Storage Temperature |
-40 °F to +185 °F (-40 °C to +85 °C) |
| Dimensions |
14.17 in x 12.60 in x 0.75 in (36 cm x 32 cm x 1.9 cm) |
| Net Weight |
2.2 lb (1 kg) |
