| CPU |
Qualcomm Cortex-A53 64-bit Quad-Core Processor 2.0 GHz |
| GPU |
Adreno 702 |
| Operating System |
Android 12 |
| RAM |
LPDDR4 3 GB (default) or 4 GB (optional) |
| Storage |
eMMC 32 GB (default) or 64 GB (optional) |
| Storage Expansion |
Supports up to 1 TB |
| Bluetooth |
2.1 EDR, 3.0 HS, 4.2 LE, 5.0 LE |
| WLAN |
802.11a/b/g/n/ac; 2.4 GHz and 5 GHz |
| 2G/3G/4G (US Version) |
LTE FDD: B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B66/B71; LTE-TDD: B41 |
| 2G/3G/4G (EU Version) |
LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28; LTE-TDD: B38/B40/B41; WCDMA: B1/B2/B4/B5/B8; GSM/EDGE: 850/900/1800/1900 MHz |
| GNSS |
GPS, (L1 + L5) – Internal Antenna |
| LCD |
7 in HD (1280 × 800), sunlight-readable, 800 nits brightness |
| Touchscreen |
Multi-point capacitive touch |
| Audio |
Built-in 2 W speaker and integrated microphone |
| Interfaces (On Tablet) |
Type-C (Input: 5 V, 1 A Max), Docking connector, Ear jack |
| Sensors |
Accelerometer, gyroscope, compass, ambient light sensor |
| USB 2.0 (Type-A) |
1 port (not usable with Type-C simultaneously) |
| RS232 |
2 ports |
| ACC Input |
0 V to 30 V |
| Power Input |
8 V to 36 V |
| GPIO |
3 inputs and 3 outputs |
| Drop Resistance |
Withstands 3.94 ft (1.2 m) drop |
| Vibration Test |
MIL-STD-810G compliant |
| Dust Resistance |
IP6x (IEC 60529) |
| Water Resistance |
IPx7 (IEC 60529) |
| Power Input |
DC 8 V to 36 V (ISO 7637-II compliant) |
| Operating Temperature |
14 °F to 149 °F (-10 °C to 65 °C) |
| Storage Temperature |
-4 °F to 158 °F (-20 °C to 70 °C) |
| Battery (Dock Version) |
3.7 V, 5000 mAh battery |
| Dimensions (W × H × D) |
8.17 in × 5.41 in × 1.19 in (207.4 mm × 137.4 mm × 30.1 mm) |
| Weight |
1.79 lb (810 g) |
