| Power Supply |
DC28 V/6.8 A |
| TX Output Frequency |
300 MHz to 8 GHz (Customizable) |
| RX Output Frequency |
300 MHz to 8GHz (Customizable) |
| RF Bandwidth |
1/2/4/8 MHz |
| RF Power Output |
43 dBm (20 W) |
| Encryption/Decryption Mode |
AES 128 bits or 256 bits (user-defined password) |
| Modulation |
COFDM 2K |
| Transfer Rate |
2×30 Mbit/s (RJ45), 115200 bps (TTL) |
| RF Connector |
N type |
| Ethernet |
RJ45 x 2, RJ232, LCD Control, TTL |
| Weight |
19.18 lb. (8.7 kg) |
| Dimensions |
12,612,401.57 in (32,021,011 cm) |
| Transmit Distance |
6.21 mil to 12.43 mil (10km -20 km) NLOS /12.43 mil to 24.85 mil (20km-40 km) LOS on ground level |
