Description
Technical Specifications
| Chipset | LoRa |
| Frequency Range | 862 MHz to 870 MHz |
| Moisture Range | 0% to 100% RH |
| Ingress Protection | IP66 (Transceiver), IP67 as required |
| Tx Power | 16 dBm (868 MHz) / 20 dBm (915 MHz) / 19 dBm (470 MHz) |
| Sensitivity | -147 dBm @ 300 bps |
| Power Supply | 19000 mAh Li-SOCL2 battery (ER34615) |
| Battery Life | 4 years (10 min interval, SF12) / >10 years (10 min interval, SF7) |
| Accuracy | ±2% (0% to 50%), ±3% (50% to 100%) |
| Resolution | 0.50% |
| Cable Length | 6.56 ft (2 m) |
| Mode | OTAA/ABP Class A |
| Operating Temperature | -22 °F to 158 °F (-30 °C to 70 °C) (Transceiver) |
| Operating Temperature | -40 °F to 185 °F (-40 °C to 85 °C) (Sensor) |
