Description
Technical Specifications
| Form | 4U rack server chassis |
| Processor | Supports two 3rd generation scalable processors |
| Chipset | C621A series chipsets |
| Internal Memory | 32 DDR4 memory slots at 3200MHz, supporting memory ECC |
| RAID Support | Supports RAID0 or 1 or 10 or 5 or 50 or 6 or 60, etc |
| Local Storage | Supports 12 or 24 (8.89 cm) 3.5-inch hard drives; Supports 8 U.2 SSDs and 2 M.2 SATA SSDs (note: 24 disk configuration requires 25degree ambient temperature support) |
| Network | Multiple network interfaces such as 10G dual port RJ45, 25G dual port fiber optic, and 10G dual port fiber optic are available for selection |
| PCI-E Extension | Supports up to 12 PCI-E4.0 × 16 slots (supports 1 OCP network card) |
| GPU Extension | Including but not limited to: NVIDIA A800 NVIDIA A30 NVIDIA A10 NVIDIA Tesla T4 NVIDIA Tesla RTX 8000P or 6000P |
| Other Interface | One independent IPMI management port Two front USB3.0 ports Two rear USB3.0 ports One front VGA port One rear VGA port |
| Power Supply | Optional 1600W or 2000WCRPS high efficiency platinum power supply, optional 3+1 or 2+2 redundancy voltage range 100-240Vac (Please refer to the power input value on the nameplate label) |
| Management Function | Integrated dual BMC chips, supporting advanced management functions such as IPMI2.0, SOL, KVMOverIP, virtual media, etc., and providing one 1Gbps RJ45 management port for external use, which can support NCSI function |
| Graphics Card | Integrated display controller, resolution 1920×1080 |
| Operating System | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, etc. |
| Operating Temperature | Working time: 41℉ to 95℉ (5℃ to 35℃) |
| Case Size (H x W x D) | 6.92 in x 17.01 in x 31.42 in (175.8 mm x 432 mm x 798mm) |
| The Full-Loaded Weight | 185.19lbs (84 KG) |
