Description
Features
- ACC detection, remote oil, SOS alarm (reserved)
- FDD/TDD/ SMS remote monitor
- Blind spot report, Turning report
- Multiple ways of positioning (GPS/BD/LBS/WI-FI)
Technical Specifications
| Parameters | Description |
| Power Supply | 9 to 90V DC |
| Current | Work current < 60 mA (DC12V) Sleep current <5 mA |
| Bands | LTE-FDD: B1, B3, B5, B8 LTE-TDD: B34, B38, B39, B40, B41 |
| Locate Mode | GPS, BD, LBS, WI-FI, AGPS |
| Positioning Time | Cold start:35S(optimal) Hot start:1S(optimal) |
| Positioning Accuracy | < 16.4 ft (< 5 m CEP |
| Sensor | Vibration sensor |
| NET Antenna | Build-in design |
| GPS Antenna | Build-in design |
| LED Description | Power, net, positioning status |
| Transport Protocol | TCP (JT808, GT06 etc) |
| Storage Temperature | -4 °F to 158 °F (-20 °C to 70 °C) |
| Backup Battery | 50 mAh (optional) |
| Operating Temperature | -4 °F to 140 °F (-20 °C to 60 °C) |
| Dimension | 3.47 in × 1.69 in × 0.63 in |
| Weight | 3.88 oz (110 g) |
