Description
Technical Specifications
| Chipset | Jinou |
| Bluetooth Veersion | Bluetooth V5.0 BR, EDR, BLE |
| RF Level | Class 1 and Class 2 |
| Frequency | 2.402GHz to 2.480GHz |
| Distance | Class 1 (100m), Class 2 (30m), in open space |
| Multiple Connection | 28pcs SPP devices or 18pcs BLE devices |
| Internet | RJ45 or Wifi |
| Power Supply | 12V 1A power adapter |
| Average Power Consumption | 120mA, 12V |
| Bluetooth Protocol | LC, LM, L2CAP, GATT, SDP, RFCOMM, SPP, HID |
| Internet Protocol | TCP IP, HTTP, FTP, ARP, DHCP, PPP, etc |
| Antenna | External antenna |
| Distance | Class 2, 30 meters in open space Class 1, 100 meters in open space |
| Multiple Connection | 28pcs SPP devices or 18pcs BLE devices |
| Power Supply | 12V 1A power adapter |
| Internet | RJ45 cable or WiFi |
| Dimension | 7.87 in x 4.72 in x 1.57 in (200 mm x 120 mm x 40 mm) |
