| Usage |
FTTH (Fiber to the Home) |
| Data Storage |
Internal: ≥3000 results, External: 4GB |
| Interface Type |
FC/PC (Interchangeable with SC, ST) |
| Connector |
Universal FC/SC/ST |
| Display |
5.8-inch color LCD with touchscreen |
| Battery Working Hours |
>10 hours |
| Reflection Accuracy |
±3 dB |
| Loss Precision |
±0.05 dB |
| Wavelength Range |
800 nm to 1700 nm |
| Calibration Wavelengths |
850 nm, 980 nm, 1300 nm, 1310 nm, 1490 nm, 1550 nm, 1625 nm (in cm) |
| Test Scope |
-50 dBm to +26 dBm |
| Relative Humidity |
0% to 95% (non-condensing) |
| Operating Temperature |
14°F to 122°F (-10°C to 50°C) |
| Storage Temperature |
-40°F to 158°F (-40°C to 70°C) |
| Dimensions |
8.9 in x 6.3 in x 2.8 in (22.7 cm x 16 cm x 7 cm) |
| Weight |
2.6 lbs (1.2 kg) |
