Description
Technical Specifications
| Chipset | nRF52810 |
| Application | Street lighting control, smart lighting |
| Supply Voltage | 6V to 36V |
| Power Consumption | 1W |
| Data Protocol | UDP or TCP or MQTT |
| Transmission Distance | City: 1.24 miles (2 Km) line of sight: 9.32 miles (15 Km) |
| Transmit Power | 23 dBm |
| Access Method | LAN,2G or 3G or 4G |
| Receive Sensitivity | -142.5 dBm |
| Antenna | 4G; LoraWAN |
| Working Temperature | -40°F to 176°F (-40 °C to 80 °C) |
| Network / Power Interface | Rj45 +DC |
| Communication Parameters | Notes |
| Operating Frequency | CN470MHz or US915MHz or EU868MHz |
| LoRa Antenna | T-NC female interface |
