Description
Features
- In accordance with GATT specification of 5.0BLE. Have good compatibility with other BLE device
- BLE getaway can monitor movement of neighboring BLE devices
- BLE gateway has WIFI function. It can connect router via RJ45 port or connect network via WIFI
- Having data caching function
- In accordance with FCC, CE, ROSH and other certificates
- Bluetooth and WIFI use different frequency, circuits and antenna
- Multi modes
- Bluetooth protocol: LL, MP, L2CAP, ATT, GATT, GAP
- WIFI supports IEEE 802.11b/g/n protocol
- Network supports: TCP/IP, DHCP, ARP, RARP, TCP, UDP
Technical Specifications
| Bluetooth Version | BLE 5.0 |
| Working Frequency | 2.40 G, 2.48 G |
| Antenna | Embedded antenna |
| Max Scanning Range | 30 m |
| Protocol | LM, LC, LL, SMP, L2CAP, ATT, GAP, GATT, SDP, RFCOMM |
| Power Supply | 5 V USB charging |
| Wireless | IEEE 802.11 b/g/n |
| Network | RJ45 and WiFi |
| Temperature | -4 °F to 149 °F (-20 °C to 65 °C) |
| Size | 4.17 in × 4.17 in × 1.18 in (10.6 cm × 10.6 cm × 3.0 cm) |
