| Interface |
USB Interface |
| Parameters |
AC Resistance, DC Voltage |
| Item |
Mobile Phone Battery Testing |
| Correction |
Short Circuit Correction for Each Range |
| Screen Size |
4.3 inches LCD Display |
| Basic Accuracy |
Resistance: ± 1 % Voltage: ± 0.1 % |
| Comparator |
200 Set WARNING / FAIL / PASS Sorting |
| Trigger |
Internal / Auto Trigger |
| Battery |
12 V / 1700 Ah Lithium Battery |
| Usage |
18650 Battery Cells Testing |
| Accessories |
Test Probe, Zero Board, Lithium Battery,DC Power Adapter, Temperature Probe, Mini USB Cable |
| Internal Data Storage |
Store Up to 2400 Test Data |
| Signal Source |
AC 1 kHz, Test Current: < 150 mA |
| Resolution |
R: 0.0011 yard (0.001 m); V: 1 mV |
| Power Supply |
2 V / 1700 mAh Lithium Battery, AA (LR6) Alkaline Batteries x 8 |
| Range |
Resistance: 3 mΩ / 30 mΩ/ 300 mΩ / 3 Ω |
| Measuring Range |
R: 0.0011 yards to 3.39 yards (0.001 m to 3.1 m); V: 1 V to 60 V |
| The Minimum Resolution |
Resistance: 1 μΩ, Voltage: 1 mV |
| The Maximum Reading |
Resistance: 31,000 Voltage: 60,000 |
| Input Impedance |
32 kΩ |
| Dimensions |
8.19 in × 2.07 in × 4.72 in (20.8 cm x 5.25 cm x 12.0 cm) |
| Weight |
1.78 pound (0.81 kg) |
