| Function |
IoT System |
| Bluetooth Protocol |
Bluetooth 5.0 |
| LTE M |
B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66/B85 |
| NB IoT |
B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28/B66/B71/B85 |
| Wi Fi |
Optional, 2.4GHz, positioning only |
| SIM Card |
Nano and eSIM |
| Beacon Access Quantity |
100 beacon messages can be received within 1s, Maximum of 15 beacon messages at one LoRa communication |
| Certification |
CE, FCC, RCM, BQB |
| Dimension |
6.30 in × 6.30 in × 2.17 in (160 mm x 160 mm x 55 mm) |
| Operating Temperature |
-40 °F to 185 °F ( -40 ℃ to +85 ℃ ) |
| Weight |
5.29 oz (150 g) |
| Peak Current |
Max. 140mA in transmit mode |
| Ingress Protection |
IP66 |
| Positioning Precision |
3 metres |
| Encryption |
AES128, X509 |
| Battery |
Li-SoCl2 19000mAhx2, Optional: 19000mAhx4/19000mAhx6 |
| Bluetooth Positioning |
Approx. 150,000 times ** |
| Standby Current |
25 μA |
| Max Current |
300 mA |
| Solar Panel |
3 W |
| Max Charging Current |
500 mA |
| Charging Rate |
Max. 1500 mAh each day |
| Battery Life |
1 month @ 10s Bluetooth receiving duration and 60 report interval |
| Certification |
CE, FCC, RCM |
