Features
- Large Capacity and Compact Design
- Powerful Service Support
- SRv6-Powered Intelligent Connection
- Comprehensive Network Slicing Functions
- Well-Designed QoS Mechanism
Technical Specifications
| Network | Wi-Fi |
| Switching Capacity | 368 Gbit or s |
| Forwarding Performance | 276 Mpps |
| Maximum Board Capability | Fixed-configuration router |
| Power Module | 2, 1+1 |
| Capacity Density (G/U) | 184 |
| CPU | 8-core 1.5 GHz |
| SDRAM | 4 GB x 1 |
| Flash memory | 64 MB |
| Storage | 8 GB |
| Maximum number of 100GE ports | 0 |
| Maximum number of 50GE ports | 2 |
| Maximum number of 25GE ports | 2 |
| Maximum number of 10GE ports | 16 |
| Maximum number of GE ports | 30 |
| Maximum number of FE ports | 30 |
| Maximum number of electrical ports | 4 |
| Redundant power supply | 1+1 |
| Maximum input cable size [mm²] | 4 mm² |
| Power supply mode | AC or HVDC built-in |
| Rated input voltage | 200 V to 240 V or 100 V to 127 V or – 48V to – 60V dual-live wire, supporting 240 V HVDC |
| Input voltage range | 100 V to 240 V or – 40 V to – 72 V |
| Maximum input current | 10A or 4 A |
| Front-end circuit breaker/fuse | ≥4A |
| Switching capacity | 368 Gbit or s (Bidirectional) |
| Maximum number of physical ports on the entire device | 32 |
| Long-term operating temperature | -40 °F to +149 °F (-40 °C to +65 °C) |
| Restriction on the operating temperature variation rate | ≤ 30° C or hour (54°F or hour) |
| Storage temperature | -40 °C to +70 °C (-40 °F to +158 °F) |
| Long-term operating relative humidity | 5% RH to 95% RH, non-condensing |
| Storage relative humidity | 5% RH to 100% RH, non-condensing |
| Storage altitude | 16404 ft (< 5000 m) |
| Dimensions (H x W x D) | 1.75 in x 17.40 in x 8.66 in (4.45 cm x 44.2 cm x 22.0 cm) |
| Weight | 9.04 Ibs (4.1 kg) |
