Description
Features
- Support 4G, Ethernet port access to the Internet, multi-network at the same time online
- 10 or 100 or 1000Mbps WAN port, 4G sim card slot, built-in Wi-Fi, GPS and Zigbee module (optional)
- Stable full Netcom speed experience, fully compatible with major operators’ 3G or 4G network
- Wired and wireless backup each other to ensure normal and stable data transmission, multi-network intelligent switching backup
- Data storage when the network is disconnected, and data transmission resume after network recovery
- Optional LoRaWAN frequency bands CN470MHz, IN865MHz, EU868MHz, RU868MHz, US915MHz, AU915MHz, AS923MHz, KR920MHz
- Support active polling of Modbus RTU devices, support configuration of protocol analysis templates, help users save the input of tedious SCADA Modbus commands, and at the same time complete protocol analysis and conversion, directly report to the platform
- Reducing protocol conversion
- Support optional NPU computing power card, 3TOPS computing power, open system, users can install Docker image or video analysis algorithm by themselves, widely used in edge computing scenarios
- Support optional NPU computing power card, 3TOPS computing power, open system, users can install Docker image or video analysis algorithm by themselves, widely used in edge computing scenarios
- Industrial Design, Metal Case, Stable 7×24 Hours Uninterrupted Work Under Various Industrial Environments & Strong Interference
- Wide range voltage AC110 V to 277 V power supply, convenient for industrial applications
Technical Specifications
| Application | Street lighting control, IoT Application |
| Network Standard | 4G, Ethernet |
| Power Supply | AC110 V to 277 V |
| Relative Humidity | ≤95% (No condensation) |
| CPU | Dual core, main frequency 880MHz |
| RAM | 256MB |
| Working Temperature | -40°F to +176°F (-40 ℃ to +80 ℃) |
| Storage Temperature | -40°F to +185°F (-40℃ to +85 ℃) |
| Dimensions | 8.07 in x 8.07 in x 2.91 in (20.5 cm x 20.5 cm x 7.4 cm) |
