| Digital Waveform Automatic Recognition |
Automatically recognizes waveforms that are difficult to identify manually. |
| Waveform Comparison Function |
Enables comparison between fault and normal cable waveforms to locate fault points clearly. |
| High-Power Lithium Battery |
Provides up to 10 hours of continuous use with a specialized charger. |
| Data Interface |
Supports remote system upgrades for customers. |
| Maximum Measurement Range (Manual Test) |
4.97 mi (8 km) |
| Maximum Measurement Range (Intelligent Test) |
2.49 mi (4 km) |
| Highest Resolution |
1.64 ft (0.5 m) |
| Power Consumption |
1 W |
| Ambient Temperature |
5 °F to 113 °F (-15 °C to +45 °C) |
| Storage Temperature |
-4 °F to 131 °F (-20 °C to +55 °C) |
| Dimensions |
7.5 in × 3.3 in × 2.0 in (19 cm × 8.4 cm × 5.2 cm) |
| Weight |
0.84 lbs (0.38 kg) |
