Temperature & Vibration Sensor for Industrial Equipment - Asset Track Pro - Image 2

Temperature & Vibration Sensor for Industrial Equipment – Asset Track Pro

Explore LoRaWAN wireless temperature and vibration monitoring with long-range communication and intrinsic safety, ideal for industrial equipment.

SKU: ATPOLED-129 Category:

Description

Features

Hardware features

  • Frequency response range: 5Hz to 2K
  • Equipment surface temperature monitoring
  • Replaceable high-capacity lithium sub battery (working for three years)
  • IP68 waterproof and dustproof protection grade
  • Super power design with anti-data loss features
  • Inside antenna, compact size
  • Temporary acquisition of waveform, spectrum, and hardware diagnosis via Bluetooth
  • LoRa and Bluetooth BLE 5.0 wireless technologies
  • Long-distance communication up to 2.5 km
  • Adopts LoRaWAN international standard
  • Triaxial acceleration and speed monitoring
  • protocol and has wide adaptability



 Software features

  • Sensor configuration via Bluetooth, easy to operate
  • Acquisition of speed and displacement
  • Network disconnection cache monitoring and automatic retransmission
  • Intelligent diagnosis algorithm



Technical Specifications

Use Monitoring system
Acceleration Number of Axes 3 axes
Sensing Unit MEMS
Amplitude Range ± 16 g peak
Accuracy ±5% (160 Hz) Z / X / Y axis
Data acquisition Acceleration Frequency Range 5 Hz (±3dB) to 2 kHz (±3dB)
Acceleration Amplitude Range ±16 g
Measurement Interval 20-minute index
Output Mode Total value, effective value
Telecommunications Bluetooth Bluetooth 5.0
Bluetooth Frequency 2.4 GHz ISM band 2.4 GHz to 2.483 GHz
Bluetooth Power 2 dBm
LoRa 470 MHz to 510 MHz
Battery Battery Model Replaceable DC 3.6 V disposable lithium
Life It can work for 3 years according to the configuration definition
Standards EMC Standard IEC 61326-1
Wireless Spectrum ETSI EN 300 328
Security Meet the technical requirements of mic short-range radio equipment
Explosion Proof Safety ExiallCT4 Zone 0 IIC gas environment
Authentication Meet CE Requirementsr
Output Digital signal
Amplifier Type IDT
Voltage – Supply 5 V
Output Type 5 V
Current – Supply 0.3 mA
Mounting Type DIP
Features Low Voltage
Current Supply (Max) 0.5
Case Plastic
Output Mode Total value, effective value
Temperature Acquisition Measuring Range -40 °F to 248 °F (-40 °C to 120 °C), (The surface temperature of the equipment shall not be confused with the working temperature of the product. The working temperature is limited by the battery. The battery is a distance from the sensing part at the bottom)
Accuracy 33.8 °F (1 °C)
Operating Temperature -13  °F to 185 °F (-25 °C to 85 °C)
Working Conditions Working Temperature -40 °F to 158 °F (-40 °C to 70 °C), (Working at or beyond the limit temperature for a long time will affect the service life of the battery and even damage the monitor)
Mechanical Parameters Corrosion Resistance Stainless steel body, solution resistant PC material
Drop Resistance No problem 3.28 ft (1 m) drop to concrete
Body Material 304 stainless steel base and reinforced impact resistant glass fiber PC upper cover
IP Level IP68 waterproof and dustproof grade
Fixing Hole M6 × 1 mm × 7 mm internal thread
Overall Dimension Height: 3.34 in (8.5 cm); Diameter: 1.69 in (4.3 cm)
Weight 8.04 oz (228 g) (including battery)
